B773
BOEING 777-300
BOEING 777-300
Aircraft
Name
777-300
Manufacturer
Body
Wide
Wing
Fixed Wing
Position
Low wing
Tail
Regular tail, mid set
WTC
H
APC
D
Type Code
L2J
Aerodrome Reference Code
4E
RFF Category
9
Engine
Jet
Engine Count
Multi
Position
Underwing mounted
Landing gear
Tricycle retractable
Manufactured as
BOEING 777-300
B773
Long range high capacity wide-body airliner. In service since 1998. Stretched version of 777-200 as replacement of the 747-100/200. Largest twin engine passenger aircraft in the world. The 777-300 has a maximum range of 6005 nm with a MTOW of 299370 kg. The 777-300ER (Extended Range)is capable of flying 7880 nm with MTOW of 351,534 kg and has a wider wingspan. The B773 is member of the B777 family of aircraft.
Technical Data
Wing span (metric)
60.90 m
Length (metric)
73.80 m
Height (metric)
18.70 m
Powerplant
2 x PW4098 (436 kN) or
2 x RR Trent 892 (400 kN) or
2 x GE90-94B (416 kN) turbofans.
Engine Model(s)
General Electric GE90
Pratt & Whitney PW4000
Rolls-Royce Trent 800
Indicative Performance Data
Take-Off
V2
168 kts
Distance
3000 m
MTOW
299370 kg
Initial Climb (to 5000 ft)
IAS
200 kts
ROC
3000 ft/min
Initial Climb (to FL150)
IAS
300 kts
ROC
2500
Initial Climb (to FL240)
IAS
300 kts
ROC
2000 ft/min
MACH Climb
MACH
0.82
ROC
1500 ft/min
Cruise
TAS
490 kts
MACH
0.84
Ceiling
430
Range
6009 NM
Initial Descent (to FL240)
MACH
0.84
ROD
1000 ft/min
Descent (to FL100)
IAS
300 kts
ROD
3000 ft/min
Descent (FL100 & below)
IAS
n/a
MCS
250 kts
ROD
n/a
Approach
Vapp (IAS)
149 kts
Distance
1800 m
